Key Advantages

Exceptional Load-Bearing Capacity: Designed to withstand extreme seismic forces, offering some of the highest load ratings available in the market.

Comprehensive Pipe Size Coverage: Compatible with pipe diameters from DN25 to DN300, providing versatile application across all major pipeline systems.

Full Angular Adaptability: Supports installation angles from 30° to 90°, enabling flexible and precise system design in complex environments.

Automated Design Software: Streamline your project planning with our proprietary software, reducing design time and ensuring code-compliant configurations.

Detailed Description:

Specifically designed for attaching seismic braces to structural steel, the FM Beam Clamp complements the FM Connector system. Featuring the same reliable breakaway bolt technology and forged construction, it ensures consistent performance across all connection points.

Key Features:

Compatible with FM Connector for system integration

Complete angular adjustment capability

 confirmation system

Forged high-strength construction

Applications:

Steel structure-to-brace connections in seismic applications

Detailed Description:

The FM Connector serves as the critical link between seismic braces and concrete structures. Engineered with a patented breakaway bolt system that provides clear visual confirmation of proper installation, this forged component delivers exceptional strength and adaptability.

Key Features:

Flexible angular adjustment for optimal force transmission

Visual installation confirmation via breakaway bolt design

Forged construction for superior material strength

Patented design achieving highest load capacity ratings

Applications:

Concrete-to-brace connections in seismic bracing systems

Full Pipe Diameter Coverage:

Suitable for DN25–DN300 pipelines, supporting complete seismic bracing solutions.

Uniform Load Distribution:

Optimized ring structure ensures stable restraint in both lateral and longitudinal directions.

Seismic Restraint Performance:

Designed to maintain pipe position during seismic movement.

Electro-Galvanized Surface:

Provides corrosion resistance for long-term indoor and semi-exposed applications.

Fire Protection Pipeline Ready:

Ideal for sprinkler and MEP pipeline seismic restraint systems.

Structural Bracing Member:

Functions as diagonal brace components within seismic bracing systems.

High Strength Steel Material:

Manufactured to meet international mechanical performance standards.

Corrosion-Resistant Finish:

Galvanized surface improves durability and service life.

Stable Load Transmission:

Provides reliable force transfer between connection points.

Seismic System Compatibility:

Designed specifically for use in seismic sway bracing assemblies.

Certified Seismic Anchor:

Validated through seismic testing for use in FM Approved bracing systems.

Cracked Concrete Application:

Approved for anchoring into cracked concrete substrates.

Secure Concrete Connection:

Ensures reliable load transfer between FM connectors and concrete structures.

Engineered For Structural Safety:

Designed for safety-critical seismic anchoring applications.

System-Matched Performance:

Optimized for use with FM Connector to ensure overall system reliability.

High Load Bearing Capacity:

Engineered to provide strong and reliable anchorage across a wide range of concrete and masonry substrates.

Verified Testing Performance:

Supported by mechanical tests, fire resistance testing and anti-corrosion performance reports.

Enhanced Corrosion Protection:

Hot-dip zinc coating ≥45μm or electrogalvanized ≥5μm for extended service life in harsh environments.

System-Compatible Design:

Suitable for integration with seismic bracing, pipe support and structural fixing systems.

Stable Supply And Technical Support:

Consistent quality control and technical documentation support for engineering projects.

Reliable Undercut Load Mechanism:

Self-expanding sleeve at the anchor bottom forms a mechanical key bearing structure, delivering stable load transfer and high anchoring reliability.

Suitable For Cracked Concrete:

Designed for use in C20 and above concrete, including cracked concrete conditions, ensuring dependable performance in complex substrates.

Certified Seismic Performance:

Passed JG/T 160 seismic S-class type inspection, supporting anchoring applications with seismic resistance requirements.

Multiple Safety Test Reports:

Backed by mechanical, cracked concrete, seismic, and fire resistance test reports, improving engineering acceptance and approval efficiency.

Engineered For Structural Fixing:

Widely used in steel structures, curtain walls, pipe supports, and equipment anchoring where safety margins are critical.
