NIO Chuzhou F4 Factory – Anti-Drop Bracing System Case Study

HOOGO Strengthens Overhead Safety for a 200,000-Unit EV Manufacturing Base with Advanced Anti-Drop Bracing Solutions

Project Overview (30-Second Summary)

Client: NIO – A leading Chinese electric vehicle manufacturer, with the Chuzhou F4 factory serving as the core production base for its new sub-brand.
Challenge: The factory features dense MEP systems, complex pipeline layouts, and high-risk environments (high voltage & humidity), requiring reliable overhead safety solutions with high load capacity, corrosion resistance, and fast installation under tight deadlines.
Solution: HOOGO delivered over 13,000 Anti-Drop Bracing Systems, supported by BIM-based engineering and optimized installation planning.
Value: Achieved safe and efficient installation across 83,000 m² core production areas, ensuring uninterrupted operation for an annual production capacity of 200,000 electric vehicles.

Client Background & Project Challenges

A High-Performance EV Manufacturing Hub

The NIO Chuzhou F4 Factory is a key project within the Yangtze River Delta integrated development plan:

• Total construction area: 126,000 m²

• Core production area: 83,000 m²

• Annual capacity: 200,000 electric vehicles

• Critical infrastructure includes:

• 42 km fire protection pipelines

• 38 km cable tray systems

• 36,000 m² HVAC duct coverage

As a highly automated smart factory, system reliability and operational continuity are essential.

Key Challenges

1. Complex & Dense MEP Infrastructure

The facility includes highly concentrated pipelines across multiple systems:

• Fire protection

• Electrical cable trays

• HVAC and smoke exhaust systems

• Process pipelines

Traditional support systems struggle to ensure safety and efficiency in such dense environments.

2. High-Risk Operating Conditions

Certain areas involve:

• High-voltage systems

• High humidity environments

• Elevated installation zones

These conditions demand superior load-bearing capacity, anti-drop safety performance, and long-term corrosion resistance.

3. Tight Construction Timeline

The project required:

• Rapid installation

• Minimal coordination conflicts

• Full compliance with national standards

All while maintaining construction quality and safety.

Compliance Requirements

All installations were required to meet:

• 18R417-2 Standard Atlas for Prefabricated Pipe Supports & Hangers

• GB50981-2014 Seismic Design Code for MEP Systems

Ensuring that critical systems (fire protection, power supply, cooling) remain functional during unexpected events.

HOOGO's Anti-Drop Bracing Solution

Product Deployment Scope

HOOGO supplied:

• 13,000+ Anti-Drop Bracing Systems

Covering:

• Fire protection pipelines

• Electrical cable trays

• HVAC and ventilation systems

• Process pipelines across the core production area

Engineering Strength & Technical Advantages

1. BIM-Driven Design for Complex Layouts

HOOGO utilized proprietary BIM software to:

• Optimize routing and support placement

• Eliminate clashes between dense systems

• Enable precise installation planning

2. Enhanced Safety with Load Margin Design

Each bracing node was engineered to:

• Exceed actual load requirements by 30%

• Provide additional safety redundancy in high-risk environments

3. Modular System for Faster Installation

Compared to traditional welded supports:

• No on-site welding required

• Pre-engineered connections simplify assembly

• Installation efficiency improved by ~30%

4. Superior Corrosion Resistance

HOOGO's patented coating technology:

• Achieves 3000+ hours of salt spray resistance

• Ensures long-term durability in humid and industrial environments

Project Results & Delivered Value

1. Significant Efficiency Improvement

With modular Anti-Drop Bracing Systems and BIM planning:

• Installation efficiency improved by approximately 30%

• Reduced labor intensity and on-site coordination challenges

2. 30% Reduction in Lifecycle Cost

Through:

• Optimized material usage

• Reduced installation time

• Lower maintenance requirements

HOOGO helped the client achieve ~30% overall cost savings.

3. Enhanced Safety & Operational Continuity

The system ensures:

• Stable and secure overhead pipeline support

• Reduced risk of falling or system failure

• Continuous operation of critical factory systems

4. Supporting High-Volume EV Production

By ensuring safe and efficient MEP system installation, HOOGO's solution directly supports:

• Reliable operation of production lines

• Stable output of 200,000 EV units annually

5. Long-Term Partnership Potential

Following the success of this project, the client has expressed strong interest in future collaboration, reinforcing HOOGO's position as a trusted partner in the EV manufacturing sector.

Why NIO Chose HOOGO

• Proven expertise in large-scale industrial projects

• Advanced BIM-based engineering capabilities

• High-performance Anti-Drop Bracing Systems

• Modular design for faster and safer installation

• Reliable durability in demanding environments

HOOGO continues to support leading manufacturers in building safer, smarter, and more efficient production facilities.
